| Place of Origin: | Shenzhen China |
| Brand Name: | CALIN |
| Certification: | STS Certificates |
| Model Number: | CA768 |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Standard Packing |
| Delivery Time: | 6 weeks |
| Supply Ability: | 500000Piece/Year |
| Material: | Steel / Aluminum On Request | Color: | White |
|---|---|---|---|
| Weight: | 2.0kg | Dimension: | 226x203x164mm |
| No. Of Chamber: | 4 | Valves: | Graphite-filled Phenolic |
| High Light: | smart gas meter,prepayment gas meter,MODBUS Prepaid Gas Meter |
||
Steel Material Smart RF Communication Remote Reading and Control Gas Meter
The CA768 is not only an unique residential gas meter applied to accurately measure volumes of natural gas, town gas liquefied petroleum gas etc, but also AMR / AMI facility with data exchange features. The revenue protection and data mangement can be realized by utilizing this meter type in any severe circumstances, delivering high performance measurement at an economical price.
Its die-cast steel case with convoluted diaphragms enables smooth operation and long life . The chamber drum is selected with European standard materials with substantial durability. This new type bridges the former steady but standalone dumb metering with up-to-date real time data acqusition and interaction of smart metering. Another outstanding feature is that this meter is integrated with latest STS standard and operates with 20 digits' token code. It offers utmost convenience and security to both consumers and service providers.
Main Features
STS Algorithm compliant
Operate in both prepaid and postpaid mode (with AMR facilities)
Light and free of maintenance
Hybrid metering in both Prepaid and post-paid mode
Low power usage and low failure rate
Non-volatile memory for over 10 years’ data storage in absence of power
Compatibility for communication such as RF, MODBUS, and RS485 (on request)
Available with EMC, ESD, EMI approval
Low credit warning
Anti-reverse device deters tampering
Parameters
| Type | G1.6 | G2.5 | G4 |
| Nominal Flow Rate m³/h | 1.6 | 2.5 | 4 |
| Maximum Flow Rate m³/h | 2.5 | 4 | 6 |
| Minimum Flow Rate m³/h | 0.016 | 0.025 | 0.040 |
| Working Preesure Pa | 0.5 | ||
| Basic Error % | Qmin<Q<0.1Qmax: ±3; 0.1Qmax<Q<Qmax: ±1.5; | ||
| Leak-Provenance kPa | No leakage below 15kPa | ||
| Pressure Loss kPa | <250 | ||
| Maximum Reading m³ | 99999.9 | ||
| Minimum Reading m³ | 0.2 | ||
| Weight(kg) | -10℃ |
||
Dimensions and diagram
