Keypad Based Wireless Power Meter 8MM Cable Single Phase Electricity Meter

Keypad Based Wireless Power Meter 8MM Cable Single Phase Electricity Meter

    • Keypad Based Wireless Power Meter 8MM Cable Single Phase Electricity Meter
  • Keypad Based Wireless Power Meter 8MM Cable Single Phase Electricity Meter

    Product Details:

    Place of Origin: China
    Brand Name: Calin
    Certification: CE/SABS/IEC
    Model Number: DDSY168-g

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Carton
    Delivery Time: 30 days
    Payment Terms: western Union,Paypal, T/T, L/C
    Supply Ability: 70,000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: 1 Phase Gprs Prepayment Wireless Meter Standard: SANS1524-1 , IEC62056-21 , IEC62053
    Dimensions: 165x112x58mm Weight: 700g
    Display: Backlit LCD 8 Digits Accuracy: Class 1s
    Com Port: Optical & RS485 Cable Size: 8mm
    High Light:

    wireless electric meters

    ,

    wireless watt meter

    Keypad Based Wireless Power Meter 8MM Cable Single Phase Electricity Meter



    The CA168-G is Calin's latest non-wired solution of single phase prepaid meter for remote STS prepayment applications. It is a two wires', 80 Amp, keypad based prepayment meter complete in a compact BS5685  footprint mounting. The meter is designed for long-distance scattered low voltage large power consumers .





    The meter is manufactured according to ISO9001 standards and is provided with IP54 rated protective class, in a wide voltage range ( Un -40% +20%) and improved RF immunity of 30V/m, enablign it to be deployed in very harsh environments. The DDSY168-G series is also provided with options for  measurement of both active and reactive energy, and 2400 bps baud rate optical port for data extraction.



    The GPRS function of DDSY168-G allows the meter to communicate with the head-end server via TCP/IP or vpn through point-to-point networks. Metering  grid supply parameters can be remotely read and collected into the head-end server automatically as scheduled task. The meter Information can be toggled by punch in different  codes of programmed combinations.. Users can retrieve metering related data from the display screen such as  present current and voltage, daily usage, monthly usage, balance, and last successfully entered tokens.









    Features

    1) Standard Transfer Specification(STS) standard encryption

    2) Build-in load switch

    3) Disconnects on overload and no credit or tamper detected

    4) RS485 and infrared optical ports for data interrogation

    5) Programmable power limit and low credit warning

    6) Emergency credit and repayment control

    7) Tamper detection and event record

    8) Recall 12 months historical usage data and last 5 successfully entered token

    9) Operates in prepayment and post-payment mode



     Utility benefits

    1) Split connection with User Interface Unit (UIU)-- optional

    2) PLC/ RF/ GPRS/GSM communication on request

    3) Time of Use (TOU) / mutil-rates and holiday settings

    4) Advanced load management and disconnection features

    5) DLMS/COSEM , IEC62056 protocol compliant



    Specifications:





    Electrical parameters:

    Nominal voltage Un

    3x240V

    Limited voltage

    60%~120%Un

    Frequency

    50/60Hz+5%

    Basic current(Ib)

    10A

    Maximum current(Imax)

    100A

    Starting current(Ist)

    30mA

    Active energy constant

    400imp/kWh

    Accuracy



    Active energy to IEC62053‐21

    Class1.0

    Reactive energy to IEC62053‐23

    Class2.0

    Power Consumption



    Power consumption in Voltage circuit

    <2W  <8VA

    Power consumption in current circuit

    <1VA

    Temperature range



    Operation meter

    25℃ to+70℃

    Storage

    40℃ to+85℃



    Insulation strength

    AC Insulation strength

    4kV at 50Hz during 1min

    Impulse voltage 1.2/50μs mains connections

    8kV





    Electro Magnetic Compatibility

    Electrostatic discharges



    Contact discharge

    8kV

    Air discharge

    16kV

    Electromagnetic RF fields



    27MHz to 500MHz typical

    10V/m

    100kHz to 1GHz typical

    30V/m

    Fast transient burst test

    4kV

    Mechanical requirements



    Protection Rating

                              IP54

    Insulation Classification

    Protective Class II

    Maximum cable size

    10 mm
