Product Details:
Place of Origin: China
Brand Name: Calin
Certification: STS
Model Number: Calinpay-s
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: No packing needed
Delivery Time: 30 days
Payment Terms: Western Union, L/C, T/T, Paypal
Supply Ability: 7,000,000
Contact Now
Detailed Product Description
Standard: STS , IEC62055-51 O/S: WINDOWS ANDROID MAC IOS
Database: ORACLE Operation: Basic PC Literacy
Framework: N/A Communication: Internet, Intranet, LAN / WAN GPRS
High Light:

electricity vending system

,

mini grid electricity

Mini Grid Oursourced proxy management electricity vending system zero hardware software investment hosted vending service

How to collect the revenue from your mini-grid?  Prepayment meter must be the best choice. Calin-pay  is a cost-effective vending and management solution for any offgrid mini-grid developers  who do not want to be hands on in the revenue collection management process. Calin-pay is already integrated with your local payment gateways. You pay minor transactional charge and the revenue will be transferred automatically to you account on periodic basis. Please contact us for details if you are interested.



Outsourced proxy vending system helps the mini-grid developers to implement a prepayment metering solution without having to invest in the vending system back-office infrastructure. Of major benefit is that Calinmeter manages the complex back-office and data servers leaving the entity to be concerned merely with the electricity sale to their customers.



Key Benefit

1)     Quick cash flow

2)     Zero cost for hardware and software maintainence staff

3)     Flexible tariff settings

4)     Scratch card vending on request

5)     Transaction reports

6)     Low operational cost

7)     Maintenance free



Oursourced Proxy Management Smart Micro Grid System Zero Hardware Software Investment Hosted Vending 0



STS prepayment electricity meter Specification Datasheet





Parameter

1 Phase

3 Phase

Nominal voltage

110/120/220/230/240Volt

Un (40%- 130%)

3x110/120/220/230/240Volt

Un(30%- 135%)

Norminal current

5(60)A

10(100)A

Connection type

Whole current / CTVT connection

Whole current / CTVT connection

Maximum current

80A

100A

Frequency

50Hz

50Hz

Accuracy class

IEC Class.1

IEC Class.1

Voltage circuit burden

≤1.5W & 1.2VA

≤1.5W & 5VA

Current circuit burden

≤0.2VA

≤0.5VA

Protective class

IP 54 as  IEC 60529

IP54 as  IEC 60529

Insulation class

6kV Class II

6.5kV Class II

Surge immunity

4 kV

4.3kV

Electrostatic discharge

15kV

16kV air discharge

Immunity to HF fields

80MHz to 2GHz@30V/m

80MHz to 2GHz@30V/m

Fast transient burst

4.3kV

4.3kV

Radio interference

As CISPR22

As CISPR22

Battery life without power

10 years

10 years

Dimension

160mmx112mmx71mm

290mmx170mmx85mm

Weight

Approximate 0.7kg

Approximate 3kg
