AMR system Prepaid Water Meters
Product Details:
Place of Origin: China
Brand Name: Calin
Certification: CE/SABS/IEC
Model Number: CA568-N
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton
Delivery Time: 30 days
Payment Terms: western Union,Paypal, T/T, L/C
Supply Ability: 10,000pcs per month
Contact Now
Detailed Product Description
Product Name: Smart Remote Reading NB-IOT Water Meter Type: Multi-jet
Protection: IP67 Display: LCD / Counter Register
Accuracy: Class B Communication: NB-IOT
Size: DN15-DN25
Highlight:

AMR System Prepaid Water Meters

,

IP67 Prepaid Water Meters

,

NB-IOT Water Meter

IP67 Smart Remote Reading Prepaid Water Meters NB-IOT Water Meter with AMR system

The CA568-N Smart Remote reading water meter adopts the advance NB-IOT (Internet of Things) communication technology, Through microelectronic control circuits, it converts the pulse signals of traditional mechanical meter into electrical signals, then the metering data is transmitted to background platform through NB-IOT network automatically

Calin prepaid water meter also works with mobile money / payment such as Mpesa, Airtel, Orange. Customers can purchase water credit token at anytime any place 24/7 through USSD or SMS, short codes on mobile phone







Features

  •  Diretive 2014/32/EU,OMIL R-49:2013(E)&EN14154 compliant
  • Wet dial / dry dial register construction on request
  • Magnetic field protection
  • Low battery consumption design, up to 8 years' battery life
  • Large capacity data storage
  • Recording neter's running information
  • Including 36 months of time-slicing information for the district metering monitoring
  • Brass / plastic meter body on request
  • Over 10 years' data storage on absence of power
  • Non-return valve preventing back-flow



Specifications:



DN mm 15 20 25 32 40 50
Size Inch 1/2" 3/4" 1" 1-1/4" 1-1/2" 2"
Q4 permanent flow m³/h 3.125 5 7.875 12.5 20 31.25
Q3 Overload flow m³/h 2.5 4 6.3 10 16 25

R80

Q3/Q1



Q2 m³/h 0.05 0.08 0.126 0.2 0.32 0.5
Q1 m³/h 0.031 0.05 0.079 0.125 0.2 0.312

R100

Q3/Q1

Q2 m³/h 0.04 0.064 0.1 0.16 0.256 0.4
Q1 m³/h 0.025 0.04 0.063 0.1 0.16 0.25

R125

Q3/Q1

Q2 m³/h 0.032 0.051 0.081 0.128 0.2 0.32
Q1 m³/h 0.02 0.032 0.05 0.08 0.128 0.2
Max.Pressure Bar 16
Pressure loss Bar 0.63 (as complete unit)
Max temperature 50
Max reading 99999

Max Permissible

Error (MPE)



%

Q1≤Q≤Q2: MPE = ±5%

Q2≤Q≤Q4:MPE = ±2%



Dimension

Size mm

DN in

15

1/2"

20

3/4"

25

1"

32

1-1/4"

40

1-1/2"

50

2"

Length(L) 165/190 190 225/260 230/260 245/300 280/300
Width(W) 99 99 103 104 124 125
Height (H) 104 106 114 117 147 172

Connecting

Thread

G3/4B G1B G1-1/4B G1-1/2B G2B G2-1/2B

Flange

ISO7005

AMR system Prepaid Water Meters 0AMR system Prepaid Water Meters 1AMR system Prepaid Water Meters 2



Calin is original meter manufaturer and solution provider, we not only produce our own products but also ODM / OEM with other meter manufacturers



AMR system Prepaid Water Meters 3
