South Africa STS Split Keypad Water Prepaid Meters with RF communication,R160 Class C

Product Details

Place of Origin: China

Brand Name: Calin

Certification: CE/SABS/IEC

Model Number: CA568

Payment & Shipping Terms

Minimum Order Quantity: Negotiation

Price: Negotiation

Packaging Details: Carton

Delivery Time: 30 days

Payment Terms: western Union,Paypal, T/T, L/C

Supply Ability: 10,000pcs per month

Get Best Price
Highlight:

prepayment water meter

,

electronic water meter

Product Name:
STS Prepaid Water Meter
Input Type:
Split CIU (Customer Interface Unit) Keypad
Weight:
1800 G (including CIU)
Display:
LCD / Counter
Accuracy:
Class C / R160
Communication:
LoRa
Product Name:
STS Prepaid Water Meter
Input Type:
Split CIU (Customer Interface Unit) Keypad
Weight:
1800 G (including CIU)
Display:
LCD / Counter
Accuracy:
Class C / R160
Communication:
LoRa
South Africa STS Split Keypad Water Prepaid Meters with RF communication,R160 Class C

South Africa STS Split Keypad Water Prepaid Meters with RF communication,R160 Class C



South Africa is the origin of STS (Standard transfer specification) standard but it is not the first one to use STS prepayment water meter. Calin as the number 47 of STS Association, is the pioneer of STS prepayment water metering in the world.   CA568  is a  multi-jet true Class C R160 accuracy, STS compliant prepaid water meter.  Most Class C STS prepaid water meter in the market is actually volumetric type and liable to get clogged and lose accuracy in grit particle water environment.  Calin's multi-jet type water meter is immune to such water quality and lasts longer years.  The meter with accuracy R160  can effectively measure the user's water consumption, it also comes with a high-capacity battery, can be used for up to 15 years.



To top-up or recharge the water meter, a consumer just need to purchase 20 digits'  credit token from the vendor and punch in the code with the CIU. With our broad range of prepaid vending solutions, a utility or service provider can manage CA568 series water meter along with STS prepaid electricity meters in one vending system.









Features

a) Can be ordered with DN15, 20 and 25

b) Recharge with 20 digits' token code

c) Split installation with wireless connection CIU

d) Tamper alarm valve shuts

e)  STS compliant prepayment algorithm

f)  IP68 water proof in flood environments

g) Non-return valve

h) Double strianers

i)  Over 10 years’ data retention in absence of power

j)  Never get clogged by grit particles

k) Ready for AMR smart metering



 Key benefits



1) Supports mobile payment

2) Quick money back and improved cashflow

3) Easy to install, operate and free of maintenance

4) Easy setting on price, overdraft and alarm level with system

5) Supports drive-by reading and AMR  reading

6) Remote reading and valve control on / off

7) Accurate billing data





Specifications:







Nominal size



Dn



mm

In-line
15 20 25
Maximum flow rate Q4 m3/h 3.125 5.0 7.875
Ratio “R” Q3/Q1   160 160 160
Permanent l flow rate Q3





m3/h

2.5 4.0 6.3
Transitional flow rate Q2 0.05 0.08 0.126
Minimum flow rate Q1 0.0156 0.025 0.039
Minimum reading



m3

0.0005
Maximum reading 99999



Maximum Permission Error (MPE)

Q1≦Q≦,Q2    MPE =+ 5%           Q2≦Q≦Q4,    MPE= + 2% (For hot water metering, MPE=+ 3%)



Dimensions and diagram



Nominal size

Length

Width

Height

Thread

mm

D

15

165

101

124

G3/4B

20

195

101

124

G1B

25

225

101

124

G5/4B
