RF Module 230Volt Prepaid Electricity Meters For Rual Electrification

RF Module 230Volt Prepaid Electricity Meters For Rual Electrification

RF Module 230Volt Prepaid Electricity Meters For Rual Electrification
RF Module 230Volt Prepaid Electricity Meters For Rual Electrification

Product Details:

Place of Origin: China
Brand Name: Calin
Certification: CE/SABS/IEC
Model Number: CA168

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton
Delivery Time: 30 days
Payment Terms: western Union,Paypal, T/T, L/C
Supply Ability: 50,000pcs per month
Contact Now
Detailed Product Description
Product Name: Nigeria MAP Single Phase Smartmeter Asset Provider Program Latch Relay: Build-in
Dimensions: 155x120x52mm Nominal Voltage Un: 220/230Volt/240 Volt
Consumption Rate: 1000 Imp/kWh Accuracy: Class 1
Split Keypad: On Request Communication: RF_LoRa
High Light:

230Volt Prepaid Electricity Meters

,

RF Module Prepaid Electricity Meters

,

230 Volt prepaid energy meter

RF Module 230Volt Prepaid Electricity Meters For Rual Electrification

RF Module Off Grid Single Phase Smart Prepaid Electricity Meter For Rual Electrification
Along with the development of off-grid, mini-grid projects worldwide, the demand for accurate prepaid smart metering is getting robust each day. Calin CA168 single phase smart prepaid electric meter operates with STS IEC62052, the only international standard for prepayment metering.  It is applicable for any off grid / mini-grid metering and revenue collection scenarios, especially for the places where the communication network is not reliable or zero since the meter can trip on tamper or credit finishes on its own without connection with the back-end server. The meter is built with SANS, IEC standards, the same as the ones supplied to the main grid power companies.

On top of the metrology features, Calin Single Phase Smart Prepaid Electricity Meter has built-in RF module that enable the meter to communicate with data concentrator and the back-end server system. This means the meter can be monitored and controlled remotely at the back-end side.  Data dashboard is available for statistic analysis.


Major Features

  1. STS encryption compliant

  2. Significant reverse energy (SRE) decrement credit as in positive current flow

  3. DLMS-COSEM standardized com port

  4. Overload and no credit disconnections

  5. Hybrid prepaid and credit mode

  6. Preconfigured load limit and low credit warning

  7. Tamper proof


 Main Benefit

  1. Wirelessly connected User Interface Unit (UIU)

  2. Smart metering  AMR  AMI features

  3. Time of Use (TOU), multi-tariff, holiday settings.

  4. Debt collection



Specifications:



Nominal voltage Un

220/230/240 volt

Limited voltage

75%~120%Un

Nominal frequency fn

50-60Hz+5%

Basic current(Ib)

5-10A

Maximum current(Imax)

60-100A

Starting current(Ist)

20mA

Active energy constant

1000imp/kWh

Accuracy as Active energy to IEC62053‐21

Class1.0

Power consumption in Voltage circuit

<2W  <8VA

Power consumption in current circuit

<1VA

Operating temperature

25℃ to+70℃

Storage temperature

40℃ to+85℃

Insulation level

4kV rms for 1min

Impulse voltage withstand

8kV, 1.2/50 μs

Air discharge

16kV

80MHz to 2GHz with load

10V/m

100kHz to 1GHz without load

30V/m

Fast transient burst test

4kV

Meter case Protection Rate

IP54(IEC60529)



 RF Module 230Volt Prepaid Electricity Meters For Rual Electrification 0RF Module 230Volt Prepaid Electricity Meters For Rual Electrification 1
