Product Details:
Place of Origin: China
Brand Name: Calin
Certification: CE/SABS/IEC
Model Number: DJGZ22-CA08A
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton
Delivery Time: 30 days
Payment Terms: western Union,Paypal, T/T, L/C
Supply Ability: 1,000pcs per month
Contact Now
Detailed Product Description
Product Name: Three Phase Data Concentrator Unit Feature: Modular Communication Unit
Dimensions: 265x170x77mm Weight: 3kg
Display: Backlit LCD 8 Digits + Icons Capacity: Downlink With Up To 500 Pcs Meters
Load Switch: N/A Material: ABS Blend With Fire Retardant
High Light:

amr solutions

,

ami systems

Data concentrator AMI Solutions Plug - in module three phase council meter



DJGZ22 intelligent data concentrator is one important part of AMI system. It connects with master station as a gateway for communication between the meters and the HES. It can perform task setting, data collection, data transmission and data storage, meter management, and task execution .



The upper communication between data concentrator and master station employs GPRS / Ethernet technology; the Down link communication between data concentrator and the meters  employs RS485/PLC /RF communication.





 Main Features

1)     GPRS uplink with head-end server (HES)

2)     Alternative com port :IR optical and RS485

3)     On demand and scheduled meter readout

4)     Remote load control overriding the consumers

5)     Non-volatile memeory for data retention

6)     IEC 62056-21 and DLMS/COSEM compliant

7)     Automatic fault alarm to HES



 Utility benefits

1)     High capacity for a hub of up to 500 pcs sub-meters

2)     Surge protection and low voltage operatable

3)     Quick and easy to install

4)     Low operational and maintenance cost

5)     Remote tariff setting, time synchronization with meters

6)     Long life time design with easy upgrade features



Data concentrator AMI Solutions Plug - in module three phase council meter 0

Specifications:



Electrical parameters:

Voltage

Nominal voltage Un

220V/380V

Extended operating voltage range

80%~115%Un

Limited voltage

60%~130%Un

Frequency



Nominal frequency fn

50Hz

tolerance

-6%~2%

Current



Basic current(Ib)

1.5(6)A

Maximum current(Imax)

10A

Starting current(Ist)

3mA

Active energy constant

6400imp/kWh

Measurement Accuracy



Active energy

1%

Reactive energy

2%

Power Consumption



Power consumption in Voltage circuit

<10W  <8VA

Power consumption in current circuit

<1VA

Temperature range



Working temperature

-35℃ to+70℃

Limited working temperature

-40℃ to+75℃



Insulation strength

AC Insulation strength

4kV at 50Hz during 1min

Impulse voltage 1.2/50μs mains connections

8kV





Electro Magnetic Compatibility

Electrostatic discharges



Contact discharge

8kV

Air discharge

16kV

Electromagnetic RF fields



27MHz to 500MHz typical

10V/m

100kHz to 1GHz typical

30V/m

Fast transient burst test

4kV





Mechanical requirements



Meter shell Protection Rate

IP51

Protection

classII
