Socket Type Residential Electric Meters Bi - Directional LCD Display Prepayment Meters

Socket Type Residential Electric Meters Bi - Directional LCD Display Prepayment Meters

    • Socket Type Residential Electric Meters Bi - Directional  LCD Display Prepayment Meters
    • Socket Type Residential Electric Meters Bi - Directional  LCD Display Prepayment Meters
  • Socket Type Residential Electric Meters Bi - Directional  LCD Display Prepayment Meters

    Product Details:

    Place of Origin: CHINA
    Brand Name: CALIN
    Certification: CE/IEC
    Model Number: CA168-A

    Payment & Shipping Terms:

    Minimum Order Quantity: 200
    Price: Negotiation
    Packaging Details: Carton
    Delivery Time: 30 working days
    Payment Terms: T/T, Western Union, MoneyGram, paypal, L/C
    Contact Now
    Detailed Product Description
    Standard: ANSI Mounting: Socket Type
    Cover: Transparent ABS Blend With Glass Flame Retardant Display: 7-digit LCD
    Input / Output: Optical Infrared Port Nominal Voltage: 120-240V
    High Light:

    single phase kwh meter

    ,

    single phase electronic meter

    Socket Type Residential Electric Meters Bi - Directional  LCD Display Prepayment Meters



    The CA168-A meter is a solid-state, socket type, single-phase residential electricity meter that provides utilities with unparalleled digital accuracy, reliability and serviceability in a cost-effective package. Personality modules in the  meter provide an array of communications and measurement options, and an optional service switch allows for remote disconnect and reconnect activities. This flexible meter platform meets current and future business needs with applications ranging from automated meter reading (AMR) to smart grid and advanced metering infrastructure (AMI) initiatives. The meter is built with VDR for surge protection up to 13 kV 6.5kA lightening.

    Major features

    1) ANSI standard compliant

    2) Demand metering functions

    3) Time-of-use (TOU) based rate structures

    4) Non-volatile memory

    5) Bi-directional active energy measurement

    6) Optical infrared port



    Specifications

    Electrical parameters

    Voltage

    Nominal voltage Un

    240V/120V

    Extended operating voltage range

    80%~115%Un

    Limited voltage

    70%~120%Un

    Frequency



    Nominal frequency fn

    60Hz

    tolerance

    5%

    Current



    Test ampere(TA)

    15A/30A

    Current class(CL)

    100A/200A

    Starting current(Ist)

    30mA

    Active energy constant

    Kh2.0

    Measurement Accuracy



    Active energy

    Class0.5

    Power Consumption



    Power consumption in Voltage circuit

    <0.8W  <4VA

    Power consumption in current circuit

    <1VA

    Temperature range



    Operation meter

    25℃ to+70℃

    Storage

    40℃ to+85℃



    Insulation strength

    Impulse voltage 1.2/50 μs mains connections

    8kV





    Electro Magnetic Compatibility

    Electrostatic discharges



    Contact discharge

    8kV

    Air discharge

    16kV

    Electromagnetic RFfields



    27MHz to 500MHz typical

    10V/m

    100kHz to 1GHz typical

    30V/m

    Fast transient burst test

    4kV





    Mechanical requirements



    Meter shell Protection Rate

    IP54

    Protection

    classII
